Power supply: 115/230 V AC, 50/60 Hz
Power consumption: 800 W 1/8 power
2 x 610 W RMS (4 ohms)
2 x 420 W RMS (8 ohms)
1200 W RMS bridged (8 ohms)
Mains input via IEC connector (M) mounting version power supply cord with safety plug
Frequency range: 20 - 20000 Hz
S/N ratio: >95 dB
THD: <0.5 % at 1 kHz
1 x temperature-controlled fan , air flow from front to rear
Impedance: Input: 20 kOhm , bal.
Input: 10 kOhm , unbal.
Slew rate: >20 V/µs
Damping factor: >350
Power switch, level control per channel, groundlift selector, limiter selector, mode switch
Short-circuit; overheat; DC voltage; power on/off transients; softstart
Status LED: Power, level meter, clip, bridged, protect
Connections: Input: line via 2 x 3-pin XLR
Input: line via 2 x 6.3 mm jack socket (mono) mounting version
Output: speaker via 2 x speaker built-in socket (F)
Output: speaker via screw terminal
Input: speaker (bridge) via 1 x speaker built-in socket (F)
Output: speaker (bridge) via screw terminal
Housing design:(19") 48.3 cm rack installation 2 U
Dimensions (WxDxH): 48.3 x 35.4 x 8.9 cm
Weight: 11.90 kg
